Insert Bearings- UK+H Type

The UK wide inner ring ball bearing uses an adapter sleeve locking mechanism and is suggested for industrial applications where normal loads are encountered. Bearing prelubricated and ready for immediate installation. The wide inner ring provides effective shaft support for a broad range of industrial applications. An external steel flinger provides additional protection from contamination. The UK series features superfinished raceways, grade-10 balls for smooth running and low noise operation. UK series wide inner ring ball bearings have spherical outside diameters for use in housings with corresponding spherical inside surfaces to compensate for shaft misalignment.

Category：

Pillow Block Bearings

WhatsApp: +8613869509899

Email: liu@changhebearing.com

Message

Product Description

Product Details

Bearing Number	Dimensions（mm）
UK205	25×52×26×17
UK206	30×62×28×19
UK207	35×72×30×20
UK208	40×80×31×21
UK209	45×85×33×22
UK210	50×90×35×24
UK211	55×100×39×25
UK212	60×110×41×27
UK213	65×120×41.5×27
UK215	75×130×44×30
UK216	80×140×48×33
UK217	85×150×50×36
UK218	90×160×51×37
UK305	25×62×27×21
UK306	30×72×30×23
UK307	35×80×34×25
UK308	40×90×36×27
UK309	45×100×39×30
UK310	50×110×42×32
UK311	55×120×44×34
UK312	60×130×48×36
UK313	65×140×49×38
UK314	70×170×52×39
UK315	75×160×56×42
UK316	80×170×58×44
UK317	85×180×61×46
UK318	90×190×66×48
UK319	95×200×67×50
UK320	100×215×74×54
UK322	110×240×82×60
UK324	120×260×86×64
